Seamless Connectivity through Wireless and
Wired Networking
Integrated with wireless functionality, power management, and I/O technologies, the ADAM-2000 series are revolutionary products for data acquisition. Based on the IEEE 802.15.4 wireless standard, networks can be easily deployed and extended. Moreover, low rates and low duty cycles make it possible for them to act as standalone devices, providing cost-effective distributed I/O solutions. With the popular industrial communication protocol Modbus RTU, ADAM-2000 series products can be adapted into any SCADA or industrial system with Advantech products, such as IPCs, ADAM, EKI, or WebAccess. |
|
 |
 |
 |
 |
 |
| 2.4GHz IEEE 802.15.4 |
Compliant with ADAM-4000/6000 |
Low-power Consumption |
Modbus RTU Protocol |
SCADA Software Support |
|
|
 |
|
|
|
 |
Overview of Wireless Sensor Networks |
|
 |
|
 |
Advantech I/O Network Solutions |
|
 |
| Through our remote I/O products, industrial communication solutions and IPC platforms, Advantech provides total solutions for many applications. Advantech’s Wireless Sensor Network I/O products, the ADAM-2000 series, helps complete remote I/O solutions and makes it even easier to expand I/O networks. |
|
|
|
|
 |
| |
|
IoT Devices - Wireless I/O |
|
|
| |
 |
 |
 |
 |
 |
| Model Name |
ADAM-2510Z |
ADAM-2520Z |
ADAM-2031Z |
ADAM-2051Z |
ADAM-2051PZ |
Link and
Download |
  |
|
|
|
|
| Description |
Wireless Router
Node |
Wireless Modbus
RTU Gateway |
Wireless
Temperature &
Humidity Sensor
Node |
Wireless 8-ch
Digital
Input Node |
Wireless 8-ch
Digital
Input Node with
Power
Amplifier |
| Function |
Router |
Coordinator |
End Device |
End Device |
End Device |
| Outdoor Range |
1000 m |
1000 m |
110 m |
110 m |
1000 m |
| Network |
Interface |
- |
RS-422/485/USB |
- |
- |
- |
Communication
Protocol |
- |
Modbus RTU |
- |
- |
- |
| Analog Input |
Channels |
- |
- |
- |
- |
- |
| Voltage Input |
- |
- |
- |
- |
- |
| Current Input |
- |
- |
- |
- |
- |
| Digital Input |
Input Channels |
- |
- |
- |
8 |
8 |
| Sensor Input |
Temperature |
- |
- |
-20°C ~ 70°C
(-4°F ~ 157.9°F) |
- |
- |
| Humidity |
- |
- |
0 ~ 100% RH |
- |
- |
| CO2 |
- |
- |
- |
- |
- |
Operating
Temperature |
External Power |
-20°C ~ 70°C (-4°F ~ 157.9°F) |
| Battery Power |
0°C ~ 50°C (32°F ~ 122°F) |
| Storage Temperature |
-40°C~ 85°C (-40°F ~ 184°F ) |
| Operation Humidity |
20~95% RH |
| Storage Humidity |
0~95% RH |
|
|
|
